DMX Splitter 4CH

Product Overview

  The DMX-4 Digital Signal Distributor & Amplifier is specially designed to reshape, amplify, and distribute the DMX512 digital lighting control signal into 4 output channels. Each input interface adopts high-voltage isolation technology, making it suitable for reshaping and amplifying DMX512 signals that have been attenuated after long-distance transmission.
  It is ideal for applications that require complete electrical isolation between the distributed output ports, as well as between the input port and all output ports. Since all interfaces are electrically isolated from each other, it can prevent the sophisticated digital lighting console from being damaged due to faults in control cables, moving heads, dimmers, or other equipment.
  This ensures the safe operation of the lighting console and maintains stable DMX signal transmission to various lighting devices, thereby improving the reliability of the entire digital lighting control system.

Key Features

  • Professionally reshapes, amplifies & distributes DMX512 signals into 4 output channels
  • Input interface with high-voltage isolation for strong anti-interference performance
  • Effectively solves signal attenuation caused by long-distance transmission
  • Protects lighting console from damage caused by external faults
  • Ensures stable signal transmission and improves system reliability

Applicable Scenarios

  • Stage performances, concerts, music festivals, outdoor light shows
  • Theaters, bars, KTV, banquet halls, wedding venues
  • Architectural lighting, landscape lighting, cultural tourism lighting projects
  • Studios, exhibition halls, large-scale lighting control systems
  • Engineering sites with strong electrical interference and long-distance transmission needs

Technical Parameter

  • 1 in 4 out
  • Reshape and amplify signal, extend the distance of signal transmission
  • Increase the device number of data bus, protect DMX512 output port of controller, and improve the safety and stability of digital light control system
  • Exterior interface of each port with enhanced circuit protection, greatly reduce damaging exterior current
  • Voltage: AC90V-240V 50HZ/60HZ
  • N.W: 1.8KG
  • G.W: 2.2KG
  • Size: 19”1U, 48.3×12.5×4.5cm
