DMX Splitter 8CH

Product Overview

  This DMX512 signal distributor and amplifier is specially designed to reshape, amplify and distribute standard DMX512 digital lighting control signals into 8 independent output channels. Each input interface is equipped with high-voltage isolation technology, making it suitable for two core scenarios: restoring and amplifying DMX512 signals that have weakened after long-distance transmission, and applications requiring full electrical isolation between all output ports, as well as between the input port and all output ports.
With independent electrical isolation across all interfaces, this device effectively prevents high-precision digital lighting consoles from being damaged by faults in control cables, moving heads, dimmer packs and other connected equipment, ensuring the safe and stable operation of the entire digital lighting system. It also guarantees consistent and stable DMX signal transmission to all types of lighting devices, further improving the overall reliability of the full lighting control system.

Key Features

  • 1 signal input, 8 independent signal outputs
  • Effectively expand the total number of connectable lighting fixtures
  • Reshape and boost signals to extend long-distance transmission range
  • Full electrical isolation between lighting fixtures and the control console
  • Strong anti-interference performance to resist external signal interference
  • Enhance overall signal stability and system operation reliability

Application Scenarios

  • Stage performances, live concerts, music festivals and outdoor large-scale light shows
  • Theaters, bars, KTV lounges, banquet halls and professional wedding venues
  • Architectural lighting, landscape lighting and cultural tourism lighting projects
  • Professional studios, exhibition halls and large-scale centralized lighting control systems
  • Engineering sites with strong electrical interference and strict long-distance transmission requirements

Technical Parameters

  • Channel configuration: 1 input, 8 outputs
  • Reshapes and amplifies DMX512 signals to extend effective signal transmission distance
  • Increases the number of connectable devices on the data bus, protects the DMX512 output port of the controller, and improves the safety and stability of the digital lighting control system
  • Reinforced external port design enhances circuit protection and greatly reduces damage from external surge currents
  • Working voltage: AC90V-240V, 50Hz/60Hz (wide voltage compatible)
  • Net weight: 1.8KG
  • Gross weight: 2.2KG
  • Product size: 19” 1U standard rack mount, 48.3×12.5×4.5cm
