CR061SA Standard Art-Net Node
Product Overview
CR061SA is a standard Art-Net node.Therefore, you can use other software, consoles, or Art-Net-compatible controllers to distribute Art-Net data via the network.It is commonly used to expand the DMX output ports of Tiger Touch or MA2 consoles.
Technical Parameters
-
CR061SA is a standard Art-Net node. It allows you to distribute Art-Net data via the network using other Art-Net compatible software, consoles and controllers. It is commonly used to expand the DMX output ports of Tiger Touch or MA2 consoles.
-
Equipped with 8 standard DMX512 data output ports, supports 8 × 170-pixel LED lights.
-
Supports both broadcast and unicast modes for Art-Net management.
-
Inputs 2 universes of Art-Net data and outputs 8 universes of DMX512 data (total output up to 4096 channels).
-
All network configuration parameters can be modified directly via the built-in buttons and display (no computer connection required for setup).
-
Installation: Standard 19-inch 1U rack-mount design.
-
Product dimensions: 48.3 × 12.5 × 4.5 cm. Net weight: 2.4 kg.
-
Package dimensions: 56 × 16 × 8 cm. Gross weight: 2.2 kg.
-
Compatible with other Art-Net supported software, consoles and controllers to distribute Art-Net data over the network.
-
Widely used to expand DMX outputs for Tiger Touch, MA2 consoles and Madrix software.
