DMX Artnet Node 8CH (Dual Network Ports)
Technical Parameter：
◆CR061SA is a standard Art-Net node . Therefore, you can use other software, consoles, and
controllers that support Art-Net to distribute Art-Net data through the network. Often used to
expand the DMX output port of Tiger Touch or MA2 console;
◆ Provides 8 standard DMX512 data output ports, supporting 8 × 170 LED pixels;
◆ Can manage ArtNet in broadcast or unicast mode;
◆ Can input 2 channels of ArtNet data and output 8 channels of DMX512 data; (a total of 4096
channels can be output);
◆ All network configuration parameters can be directly modified through the built-in buttons
and display (no need to connect to a computer for setting);
◆ Installation method: Standard 19-inch 1U cabinet installation design;
◆ Product size: 48.3×12.5×4.5cm. Net weight: 2.4kg
◆ Packing size: 56×16×8cm. Gross weight: 2.2kg
◆ Can use other software, consoles, controllers that support Art-Net, and distribute Art-Net
data through the network;
◆ Often used to expand the DMX output of Tiger Touch or MA2 consoles, as well as Madrix
software.
