RDMX-8F

8-way RDM/DMX signal distributor

 Technical Parameter：

power supply                               AC90-240V  50HZ /60Hz
Input/Output Signal Protocol    The internationally recognized RDM/DMX protocol
Bidirectional signal transmission    Support
transmission capacity                                      Can support real-time transmission of data from 512-1024 channels
signal output    Two group of 1-in-4-out or one group of 1-in-8-out signals with electrical isolation for distribution and output
Signal connection socket    Input XLR-3/5-M, output XLR-3/5-F
interface type    RS-485
Input to output electrical isolation withstand voltage    ＞AC300V
Size    484*45*140mm   “19”1U
Weight    1.8KG
